An Excel-like grid component for React with custom cell editors, performant scroll & resizable columns
This is an Excel-like Spreadsheet Grid component that supports:
✅ Custom cell editors (use built-in Input and Select, or any other components) & header content
✅ Performant scroll for as many rows as you need
✅ Resizable columns
✅ Control by mouse & from keyboard
✅ Flexible setting of disabled cells
✅ Lazy loading support
✅ Customizable CSS styling
✅ Hooks compatible
✅ TypeScript compatible
- Live playground
- Installation
- A primitive example
- The pattern of regular usage
- Props
- Public methods
- Customizing cells & header content
- Performant scroll
- Resizable columns
- Control by mouse & from keyboard
- Lazy loading support
- Customizing CSS styles
For examples of the grid in action, you can run the demo on your own computer:
- Clone this repository
npm installnpm run storybook- Visit http://localhost:6006/
This module is distributed via npm and should be installed as one of your project's dependencies:
npm install --save react-spreadsheet-grid
⚠️ IMPORTANT! This package also depends onreact,react-domandprop-types. Please make sure you have those installed as well.
import React, { useState } from 'react'
import { Grid, Input, Select } from 'react-spreadsheet-grid'
const rows = [
{ id: 'user1', name: 'John Doe', positionId: 'position1' },
// and so on...
];
const MyAwesomeGrid = () => {
return (
<Grid
columns={[
{
title: () => 'Name',
value: (row, { focus }) => {
return (
<Input
value={row.name}
focus={focus}
/>
);
}
}, {
title: () => 'Position',
value: (row, { focus }) => {
return (
<Select
value={row.positionId}
isOpen={focus}
items={somePositions}
/>
);
}
}
]}
rows={rows}
getRowKey={row => row.id}
/>
)
}Take a closer look at 2 main thing: a declaration of columns and work with the state of the parent component.
To get the correct behavior of the grid you should:
- Store rows and columns of the grid in the state of the parent component.
- Describe how the grid renders values of the cells.
- Have a callback that changes values of the rows in the state of the parent component.
Let's see how it works:
import { Grid, Input, Select } from 'react-spreadsheet-grid'
import AwesomeAutocomplete from 'awesome-autocomplete'
const rows = [
{ id: 'user1', name: 'John Doe', positionId: 'position1', managerId: 'manager1' },
// and so on...
];
const MyAwesomeGrid = () => {
// Rows are stored in the state.
const [rows, setRows] = useState(rows);
// A callback called every time a value changed.
// Every time it save a new value to the state.
const onFieldChange = (rowId, field) => (value) => {
// Find the row that is being changed
const row = rows.find({ id } => id === rowId);
// Change a value of a field
row[field] = value;
setRows([].concat(rows))
}
const initColumns = () => [
{
title: () => 'Name',
value: (row, { focus }) => {
// You can use the built-in Input.
return (
<Input
value={row.name}
focus={focus}
onChange={onFieldChange(row.id, 'name')}
/>
);
}
}, {
title: () => 'Position',
value: (row, { focus }) => {
// You can use the built-in Select.
return (
<Select
value={row.positionId}
isOpen={focus}
items={somePositions}
onChange={onFieldChange(row.id, 'positionId')}
/>
);
}
}, {
title: () => 'Manager',
value: (row, { active, focus }) => {
// You can use whatever component you want to change a value.
return (
<AwesomeAutocomplete
value={row.managerId}
active={active}
focus={focus}
onSelectItem={onFieldChange(row.id, 'managerId')}
/>
);
}
}
]
return (
<Grid
columns={initColumns()}
rows={rows}
isColumnsResizable
onColumnResize={onColumnResize}
getRowKey={row => row.id}
/>
)
}arrayOf({
id: string / number,
title: string / func,
value: string / func(row, { active, focus, disabled }),
width: number,
getCellClassName: func(row)
})defaults to
[]
required
This is the most important prop that defines columns of the table. Every item of the array is responsible for the corresponding column.
| key | Required | Mission |
|---|---|---|
id |
yes | An identifier of a row. |
title |
yes | This is what you want to put in the header of the column, it could be passed as a string or as a func returning a React element. |
value |
yes | This is content of the cell. Works the same way as title, but func receives row and current state of the cell ({ active, focus, disabled }) as parameters, so you can create an output based on them. |
width |
no | Pass this property if you want to initialize the width of a column. You can set width not for all the columns, then the rest of the table width would be distributed between the columns with unspecified width. Also, you can get width of the columns from onColumnResize callback to store somewhere and use for the next render to make columns stay the same width. |
getCellClassName |
no | An additional class name getter for a row. |
arrayOf(any)| defaults to[]
required
This is an array of rows for the table. Every row will be passed to a column.value func (if you use it).
func(row)
required
This is a func that must return unique key for a row based on this row in a parameter.
string| defaults to"There are no rows"
Used as a placeholder text when the rows array is empty.
func(row, columnId): bool
Use this func to define what cells are disabled in the table. It gets row and columnId (defined as column.id in a columns array) as parameters and identifiers of a cell. It should return boolean true / false. A disabled cell gets special CSS-class and styles. Also, you can define a column.value output based on the disabled state parameter.
func(row, columnId)
A click handler function for a cell. It gets row and columnId (defined as column.id in the columns array) as parameters and identifiers of a cell.
func({ x, y })
A callback called every time the active cell is changed. It gets { x, y } coordinates of the new active cell as parameters.
number| defaults to40
The height of the header of the table in pixels.
number| defaults to48
The height of a row of the table in pixels.
boolean
defaults to
false
By default, double clicking a cell sets the focus on the cell's input. Pass true if you want to set the focus on the cell's input upon single clicking it.
bool| defaults tofalse
Switch this on if you want the table provides an opportunity to resize column width.
func(widthValues: object)
A callback called every time the width of a column was resized. Gets widthValues object as a parameter. widthValues is a map of values of width for all the columns in percents (columnId - value).
boolean
defaults to
true
This defines should a grid has a scrollable container inside of a DOM-element where it was rendered, or not. When it turned on (by default), only visible rows are rendered and that improves performance. If you pass false, all the rows will be rendered at once (that is not a good way to handle with a big amount of them), but you will have opportunity to set up a scroll area where you want it to be and have other components (before or after the grid) included in this area.
func(scrollPosition: number)
A callback called every time the position of the scroll of the grid was changed.
func()
A callback called when the scroll of the grid reaches its bottom value. Usually, it could be used to implement the lazy loading feature in your grid (see the Lazy loading support section for details).
Use public methods via a grid's ref:
const GridWrapper = () => {
const gridRef = React.createRef()
React.useEffect(() => {
gridRef.current.resetScroll()
})
return (
<Grid
ref={gridRef}
// other props
/>
)
}Call to reset the scroll to the top of the container.
Call to make the cell with this x, y coordinates (starting from 0) active and focused.
You can customize content of titles and cells using title and value keys of elements of the columns property. Setting these components using row and { active, focus, disabled } parameters of the functions.
title could be a string or a func returning any React element.
value works the same way, but func receives current row and current state of the cell ({ active, focused, disabled }) as parameters, so you can create an output based on them.
For the basic usage, the library provide 2 default components that you can use out-of-the-box: Input and Select. Perhaps, they will be enough for you. However, you can use any other React components for that purpose: autocompletes, checkboxes, etc.
Input prop types:
| Prop | Type | Mission |
|---|---|---|
value |
string | The value of the input |
placeholder |
string | Placeholder displaying when there is no value |
focus |
bool | Should the input has focus or not |
selectTextOnFocus |
bool | Should the input content be selected when focused or not |
onChange |
func | Blur callback. Use it to catch a changed value |
Usage:
import { Grid, Input } from 'react-spreadsheet-grid'
<Grid
columns={[
{
id: 'name',
title: () => {
return <span>Name</span>
},
value: (row, { focus }) => {
return (
<Input
value={row.name}
focus={focus}
onChange={onFieldChange(row.id, 'name')}
/>
);
}
}
]}
/>Select prop types:
| Prop | Type | Mission |
|---|---|---|
items |
arrayOf({ id: string / number, name: string }) | Items for select |
selectedId |
string / number | Id of a selected item |
placeholder |
string | Placeholder displaying when there is no selected item |
isOpen |
bool | Should the select be open or not |
onChange |
func | Change item callback. Use it to catch a changed value |
Usage:
import { Grid, Select } from 'react-spreadsheet-grid'
const positions = [{
id: 1,
name: 'Frontend developer'
}, {
id: 2,
name: 'Backend developer'
}];
<Grid
columns={[
{
id: 'position',
title: () => {
return <span>Position</span>
},
value: (row, { focus }) => {
return (
<Select
items={positions}
selectedId={row.positionId}
isOpen={focus}
onChange={onFieldChange(row.id, 'positionId')}
/>
);
}
}
]}
/>Let's suggest you need to use an autocomplete as a content of a cell. This is how it could be done:
import { Grid } from 'react-spreadsheet-grid'
import AwesomeAutocomplete from 'awesome-autocomplete'
<Grid
columns={[
{
id: 'manager',
title: () => {
return <span>Manager</span>
},
value: (row, { focus, active }) => {
return (
<AwesomeAutocomplete
value={row.managerId}
active={active}
focus={focus}
onSelectItem={onFieldChange(row.id, 'managerId')}
/>
);
}
}
]}
/>A behavior of scroll depends on the isScrollable prop.
If isScrollable is false, the grid renders all the passed rows without a scroll. Probably, this would be useful for small amount of the rows.
If isScrollable is true, the height of the grid is equal to the height of its container, it has a scroll and renders only the rows that are visible. Therefore, you can pass to it as many rows as you want - it will work fine without any problems with rendering and scroll. This would be useful for big amount of the rows.
This is an example, how we could make a 500px height scrollable grid:
<div style={{ height: '500px' }}>
<Grid
isScrollable
/* other props */
/>
</div>react-spreadsheet-grid provides the opportunity to set initial width values for columns, to resize them from the UI and to react on these changes. Use relevant columnWidthValues, isColumnsResizable and onColumnResize properties for that purpose.
This is how it could be done:
import React, { useState } from 'react'
import { Grid } from 'react-spreadsheet-grid'
const ResizableGrid = () => {
// Put columns to the state to be able to store there their width values.
const [columns, setColumns] = useState(initColumns())
// Change columns width values in the state to not lose them.
const onColumnResize = (widthValues) => {
const newColumns = [].concat(columns)
Object.keys(widthValues).forEach((columnId) => {
newColumns[columnId].width = widthValues[columnId]
})
setColumns(newColumns)
}
return (
<Grid
columns={columns}
isColumnsResizable
onColumnResize={onColumnResize}
rows={/* some rows here */}
getRowKey={row => row.id}
/>
)
}react-spreadsheet-grid could be controlled by a mouse and from keyboard (just like Excel-table could). When a mouse is used, single click make a cell active, double click make a cell focused. When a keyboard used, ← → ↑ ↓ move active cell, ENTER and TAB make a cell focused.
Right now, the easiest way to tweak react-spreadsheet-grid is to create another stylesheet to override the default styles. For example, you could create a file named react_spreadsheet_grid_overrides.css with the following contents:
.SpreadsheetGrid__cell_active {
box-shadow: inset 0 0 0 2px green;
}This would override the color of borders for the table active cell.
headerHeight and rowHeight props to redefine height of the header and rows to not broke the scroll of the table.
react-spreadsheet-grid provides the opportunity to implement the lazy loading feature in your grid. Use the onScrollReachesBottom callback to handle a situation when the scroll position reaches its bottom. Load a new portion of the rows and put them in the state of a high-order component.
This is how it could be done:
import React, { useState } from 'react'
import { Grid } from 'react-spreadsheet-grid'
const LazyLoadingGrid = () => {
/* Init the state with the initial portion of the rows */
const [rows, setRows] = useState(initialRows);
const onScrollReachesBottom = () => {
loadNewPortionOfRows().then((newRows) => {
setRows(rows.concat(newRows));
});
}
const loadNewPortionOfRows = () => {
/* an ajax request here */
}
return (
<Grid
columns={/* some columns here */}
row={rows}
getRowKey={row => row.id}
onScrollReachesBottom={onScrollReachesBottom}
/>
)
}
