visualization's Introduction

This repository contains some of the work completed by me and anther student during a visualization course in my master's program.

The code is written in R with mostly using packages like ggplot2, plotly, dplyr, tidyr and shiny. The work is done in Rmarkdown and html's have been generated, but they could be too large to view here on github.

The labs contain various types of graphs and problems, increasing in complexity!

lab 1: Density plots in ggplot and plotly and a shiny app!

lab 2: Scatterplots created with ggplot and non-metric MDS on baseball data

lab 3: Maps created with Mapbox and plotly(plot_geo)

lab 4: Heatmaps and parallel coordinatet created with plotly and trellis plot with ggplot

lab 5: Several motions graphs created with visNetwork and plotly

lab 6: Word clouds created with wordcloud package and different interactive plots with filter, brushing etc created with plotly.

If you have any questions regarding the work, please contact me

A simple shiny app

library(dplyr)
library(ggplot2)
library(gridExtra)
library(plotly)
library(shiny)

# read the space delimited file into R
data <- read.delim('SENIC.txt', header=FALSE, sep = "")

# column name vector according to SENIC.pdf
var_name = c('ID', 'X1','X2','X3','X4','X5','X6','X7','X8','X9','X10','X11')
colnames(data) = var_name # change column names
 # changing the integer columns to numeric
data[,c(7,10,11)] <- sapply(data[,c(7,10,11)],as.numeric)


# Text to describe the variables
text<- c('Identification Number',
         'Length of Stay',
         'Age',
         'Infection Risk',
         'Routine Culturing Ratio',
         'Routine Chest X-ray Ratio',
         'Number of Beds' ,
         'Medical School Affiliation' ,
         'Region',
         'Average Daily Census',
         'Number of Nurses',
         'Available Facilities & Services')

ui <- fluidPage( # Slider input
  sliderInput(inputId="ws", label="Choose bandwidth size", value=0.1, min=0.1, max=1),

  # Checkbox input for all variables except X3
  checkboxGroupInput('Variable', 'Variables to choose for graphs',
                           c('X1 - Length of Stay' = 1,
                           'X2 - Age' = 2,
                           'X4 - Routine Culturing Ratio' = 4,
                           'X5 - Routine Chest X-ray Ratio' = 5,
                           'X6 - Number of Beds' = 6,
                           'X9 - Average Daily Census' = 9,
                           'X10 - Number of Nurses' = 10,
                           'X11 - Available Facilities & Services' = 11)),

  plotOutput("densPlot") # output
)

server <- function(input, output,session) {

  output$densPlot <- renderPlot({

    p_list <- list()
    for (i in c(2,3,5,6,7,8,9,10,11,12)){
      var_name <- colnames(data[,2:12]) # Assigning the names
          # using the function to collect the outliers
      indice <- data.frame(data[quantile_func(data[,i]),i])
      colnames(indice) <- var_name[i-1]
      indice$Y <- rep(0,nrow(indice))
      # creating the plot and assigningn it to p1,p2 etc...
      p_list[[i-1]] <- ggplot(data,aes_string(x= var_name[i-1] ))  +
                   geom_density(bw=input$ws,fill=8,alpha=0.7) +
        geom_point(data=indice,aes(y=Y),shape=5)+ ylab('Density') +
         xlab(text[i]) + theme_bw()
    }
         # Controlling that at least 1 box is marked for a graph to be printed
    if (length(input$Variable) >=1){
    grid.arrange(grobs = p_list[as.numeric(input$Variable)])}
  })

}

# Run the application
shinyApp(ui = ui, server = server)

A map of Sweden with Linköping pointed out as a red dot

Starting with merging a csv and JSONfile

library(dplyr)
library(plotly)
library(rjson)
library(geojsonio)
library(sf)
library(stringr)
library(tidyr)

# changed the encoding to get the åäö in the names
data_scb <- read.csv("000006SW_20230912-130931.csv",fileEncoding = "ISO-8859-1")

data_json <- fromJSON(file="gadm41_SWE_1.json")

# splitting the age variable
data_scb <- spread(data_scb, key=age, value=X2016)

colnames(data_scb)[2:4] <- c('Young', 'Adult', 'Senior')
data_scb$region <- str_replace(data_scb$region,' county','')

data_scb$region <- gsub("[[:digit:] ]", "",data_scb$region )

# örebro is Orebro in json file..
data_scb$region[data_scb$region=='Örebro'] <- 'Orebro'
# there is also numbers and spaces for each region so that
# will have to be taken care of for a possible merge

g=list(fitbounds="locations", visible=FALSE)

p<-plot_geo(data_scb)%>%add_trace(type="choropleth",geojson=data_json, locations=~region,
                                  z=~Young, featureidkey="properties.NAME_1",name="")%>%
  add_trace(lat = ~58.41109, lon = ~15.62565, type='markers',marker=list(color="red"),
          name='Linköping') %>% # changed the color
  layout(geo=g, showlegend = FALSE) # and name on the marker to red and Linköping!
p
