Somewhere between a tutorial and an anatomy of a simple Flask app with PostgreSQL and Heroku.

We're doing important work here... enabling users to vote for their favorite of these two pictures:

View an example here:

While the resulting application is different, the structure of this project is adapted from a wonderful tutorial by Felipe Florencio Garcia. For a step-by-step approach on how to get (basically) here, I highly recommend it.

Ultimately, the hope for this repository is to demonstrate/visualize the relationships between the different components of this Flask app.

• Flask app structure
  • Configuration files:
    • config.py
    • .env / Heroku config vars
  • Database / data modeling:
    • database.py
    • model.py
    • commands.py
  • The app itself:
    • app.py
• Webservice logic
  • Default endpoint
  • Home page HTML
  • The '/add' endpoint

Our Flask app is constructed from a number of interconnecting scripts. The diagram below shows (roughly) how they interact.

Note that on the right-hand side, the unlabeled arrows just represent import statements, e.g. model.py importing something from database.py.

On the left side, we have app.py calling app.config..., which makes use of config.py. And both app.py and config.py make use of shell-level environment variables using the os module.

We'll get into the details below:

We want to run our application in two different configurations:

• Production: This configuration is for the actual deployment on Heroku.
• Development: This configuration is for our own use while developing the app. We tell Flask to enable debugging, so that our server restarts whenever we save app.py. We also set the URL for our PostgreSQL database to our local, development database.

We don't want to expose the endpoint for our database, so we're going to save the URL in a shell environment variable called DATABASE_URL. We could do this manually by running export DATABASE_URL=<url here>, but instead we're going to save these variables somewhere our app knows how to access them.

• On our local machine, create a text file named .env. Make sure that this file is listed in your .gitignore. If you're using the standard Python .gitignore, it will be listed. As a result, .env won't be tracked in your repository, and your secrets will be safe with you.
• Write to .env like you see below, replacing <url here> with the actual URL for your database. It probably looks something like postgres://admin@localhost:password@dbflask, but generally, it has the form postgres://<user>@<host>:<password>@<database_name>.

APPLICATION_SETTINGS=config.DevelopmentConfig(base)
DATABASE_URL= <url here>

Now, when you flask run or heroku local web on your own machine, the application will be able to use these values.

1. $APPLICATION_SETTINGS is referenced in app.py, and is used to call the appropriate class from config.py. When we run locally, this means we use the class DevelopmentConfig(base).
2. DATABASE_URL is referenced in config.py.

On Heroku, this will work a bit differently.

1. Open the Heroku Console.
2. Navigate to your application's settings.
3. Look for "reveal config vars" and click it.
4. Fill in those key-value pairs. You should likely already see a value for DATABASE_URL, so create a new one with:

• APP_SETTINGS : config.ProductionConfig(base)

It is very important to keep these kinds of values out of your public repository. If your DATABASE_URL was exposed, it would be a security concern. That might not seem too important in a setting like this, but it's a common (and important) pattern in software development. Similarly, if your app uses anything like private API keys, or really any information that should be protected, this is a good way to handle it.

It may not seem like this script does very much. In some ways, this is true. Ultimately, it just creates a SQLAlchemy() object, then defines a function.

• One thing to keep in mind: since db is instantiated in this script, we can actually reference this object later. Often, we think of import ... as loading in functions and classes, but in fact it also imports objects of arbitrary types.

This one is pretty short, as well. We only do 2 things:

1. Import the db object from database.py.

• This creates a relationship between our data model (literally the Model class) and our database connection.
• This, in turn, makes it very easy for Flask to set up the database with the commands we create in commands.py.

1. Define the data model. This Model class will become a table in our Postgres database.

Note that we're using flask_sqlalchemy here - a package which, unsurprisingly, makes it easier to integrate Flask and SQLAlchemy. As a result, the Model class actually inherits from db.Model, which is bound to our db object.

You can read more about flask_sqlalchemy here.

On the specification of the data model:

1. We define a column called row_id as a primary key. When we create new rows/objects in our database, we will leave the row_id argument blank, and SQLAlchemy will automatically treat it as a range-style index.
2. We have a time stamp column for when each vote is recorded. We use a default value of db.func.current_timestamp() so that the time is recorded automatically.
3. We say that the vote column should be non-nullable, i.e. it cannot contain missing values. If we wanted to, we could enforce more structure on our columns. We could add a CONSTRAINT on this column so that it can only take the expected vote values "Gummi" and "Pita". We're keeping it simple for now, but it's not a bad idea.

Since our application combines multiple services, a web server and an external database, setting everything up gets a little more complicated. In this script, we define some Flask CLI commands for dealing with our database.

Notably, we can use the command flask db_create_all to create all the tables currently described in our SQLAlchemy data model. Since commands.py imports from model.py, it has registered all data tables and the relationships between them. Similarly, since it imports db from database, it knows which PostgreSQL database it's working with.

If we didn't have this command, we would have to do one of the following things:

1. Create the tables manually. This might mean opening an interactive Postgres shell with psql (locally) or heroku pg:psql for our production app.
2. Maintain another file that specifies the database schema in raw SQL.

In either case, we would be describing the structure of the database in two different places (models.py and e.g. schema.sql), and this gets harder to maintain.

Creating these Flask CLI commands, then, is powerful. It means that our SQLAlchemy specification in models.py can completely define the relational structure of our database, and it saves us a lot of work.

With all the other pieces in place, this part is rather straightforward. Essentially, this script does the following:

1. Import external libraries and local modules
2. Create and configure the flask application
3. Set up the database connection
4. Register the Flask CLI commands

Then, it defines 2 endpoints:

1. @app.route("/")
2. @app.route("/add"):

Below, we'll go over the logic of the web application in more detail.

Once our Flask app is deployed, we have a functional web server, and we can make client-side requests. In simpler terms, we can visit our website.

We defined endpoints in app.py which can be reached from an HTTP request.

This endpoint corresponds to our home page. It will query the database for the current number of votes for the images we're voting on:

• My cat, Pita, dressed as a donut.
• My girlfriend's cat, Mia, dressed as a donut.

Then, it uses the results of these queries to populate index.html.

• If you look at templates/index.html, you will see things syntax that looks like {{pita_votes}} among the typical HTML. These are handled by Flask and Jinja2. When we write something like

pita_votes = Model.query...
render_template('index.html', pita_votes=pita_votes)

That means that the Python object pita_votes will being parsed by Jinja2 and substituted for the {{pita_votes}} placeholders. You can also do things like create for-loops in Jinja2, but we keep it pretty simple here.

Let's talk about the HTML itself.

Ultimately, the only content the client ever sees is in templates\index.html. This HTML document contains the cat pictures as well as a <form> tag. Here's a simplified version of that form:

<form action='add'>
  <button type="submit" name="vote" value="Gummi">Vote for Fruit Gummi!</button>
  <button type="submit" name="vote" value="Pita">Vote for Pita!</button>
</form>

You may notice some additional attributes in some of these tags in the actual HTML file. These refer to Bootstrap classes, and handle styling of the web page. I won't get into this, but I recommend looking into their documentation.

Functionally, there are only two working elements inside the form. When we click either button, the form is submitted. And where is it submitted? Note the action='add' in the <form> tag. That means that the contents of this form are sent to our /add endpoint in a POST request, which then takes us to:

Our web form makes a POST request to '/add', at which point the following things happen:

1. The application captures the values sent in the form, namely, which cat the client voted for.
2. Then, it creates a new instance of type Model. This is from our sqlalchemy ORM, and represents a row in the database.
3. This new row/vote is inserted and committed to the database.
4. Finally, we are redirected back to the default endpoint. We see our index.html all over again. But of course, we see the updated vote totals.
